Pre Filter

HVAC Pre Filters (G1–G4 / MERV 6–8) for AHU & Projects | ZOSLONG Factory



Engineered as the initial stage in HVAC systems and air handling units (AHUs) to capture coarse airborne particulates with a diameter of Ф ≥ 5.0 μm.

Effectively shields downstream Medium-efficiency (F5–F8) and High-efficiency HEPA (H13–H14) filters from premature clogging, substantially lowering overall maintenance overhead and system lifecycle energy costs.



Application Fields

Commercial & Residential HVAC

Central air conditioning, AHUs, and fresh air intake systems in office complexes, shopping centers, airports, and public venues.

Cleanroom Pre-filtration Stages

Primary stage intake protection for pharmaceuticals, semiconductor fabrication facilities, food processing plants, and hospital surgical suites.

Industrial Exhaust & Ventilation

:Intake filtration for automotive spray paint booths, data center ventilation, industrial air compressors, and gas turbine intake stages.



Technical Specifications & Grades

Filter Grade Efficiency (Gravimetric) Target Particle Size Initial Resistance (Pa) Final Resistance (Pa)
G2 65% – 75% Φ≥5 μm 30 – 40 Pa 100 – 200 Pa
G3 75% – 80% Φ≥5 μm 30 – 40 Pa 100 – 200 Pa
G4 95% Φ≥5 μm 40 – 50 Pa 150 – 250 Pa



Style construction

Filter Type Structure Available Frame Materials Standard Depth  Advantages
Panel Filter

Ultra-slim design with flat filter pad

·Galvanized Steel

·Stainless Steel

·Aluminum Alloy

8 – 25 mm Compact profile, lightweight, ideal for shallow plenum spaces & fan coil units (FCUs).
Pleated Filter

·Pleated media backed with wire support grid

20 – 90 mm Expanded surface area, low air resistance, high dust-holding capacity.
·Heavy-duty inner/outer separable frame 46 – 96 mm Quick-release design for easy, low-cost media replacement; reusable outer frame.
·Reinforced with internal rigid tubing support Galvanized Steel / Stainless Steel / Aluminum Alloy (Tubes: Galvanized / Aluminum) 46 – 150 mm

Maximum structural strength; resists buckling and deformation under high air velocities.



Customization & OEM Services

Custom Category  Available Specifications
Dimensions & Depth

• Face Dimensions: Fully customizable (W × H)
• Thickness: Tailored from 8 mm to 150 mm

Frame Materials

• Aluminum Alloy: Lightweight, anodized, corrosion-resistant
• Galvanized Steel: Cost-effective, high mechanical strength
• Stainless Steel (SUS201/304): High temperature & acid/alkali resistance

Filter Media Options

• Synthetic non-woven fibers (G2–G4)
• Fiberglass media
• Washable expanded aluminum diamond mesh
• High-density woven nylon mesh

Sealing & Hardware

• Continuous PU foam gasket / EVA / EPDM strip seals
• Single-sided or double-sided protective faceguards

Branding & Packaging

• Laser-etched frame logos / Private label printing
• Airflow direction arrows & specification labeling
• Individual polybags + heavy-duty export pallet packaging

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -



  • Activated Carbon Pleated Air Filter
    Activated Carbon Pleated Air Filter | Air Purifier Replacement Filter
    Activated carbon pleated air filter for air purifiers, fresh air units and ventilation equipment. Combines a honeycomb...
    read more
  • Antibacterial Panel Filter
    HMA Antibacterial Panel Filter for Air Conditioning and Air Purification Equipment
    HMA antibacterial panel filter made with polypropylene media for low resistance air filtration in air...
    read more
  • Paint Booth Ceiling Filters
    A Paint Mist Interception Solution for More Stable Airflow in Spray Booths
    HBDPA ceiling paint mist filter cotton is an air filtration material specifically designed for roof-mounted air...
    read more
  • Plastic Frame Synthetic Fiber Pleated Prefilter
    Plastic Frame Synthetic Fiber Pleated Prefilter for HVAC and AHU Systems
    Plastic frame synthetic fiber pleated prefilter for HVAC, AHU, and ventilation systems. Lightweight, low-resistance,...
    read more
  • G3 High Temperature Pleated Prefilter
    High Temperature Pleated Prefilter for Oven and Thermal Process Air Systems
    High temperature pleated prefilter for oven, drying, and coating air systems. Designed for primary-stage...
    read more
  • 20 Inch Pre Filter
    20 Inch Pre Filter – Industrial-Grade Air Filtration for Demanding Applications


    Our 20-inch pre-filter is specifically designed for HVAC systems in commercial and industrial...
    read more
  • Cleanable Furnace Filter
    ✅ Cleanable Furnace Filter – Durable, Eco-Friendly & Cost-Effective


    A cost-effective, eco-friendly alternative to disposable filters with our cleanable furnace filter. Built...
    read more
  • Synthetic Fiber Filter
    Durable Synthetic Fiber Filter | Pre-Filtration for HVAC Systems
    High-performance synthetic fiber filter for HVAC systems. Efficient coarse particle capture, low resistance, and long...
    read more
  • Clean Reusable Furnace Filter
    Washable MERV 11 Furnace Filters: A Money-Saving HVAC System
    Cleanable, long-lasting, good filtration, and cost-effective - this MERV11 furnace filter is the "money-saver" for your HVAC system!
    read more
  • Commercial MERV 8 Filter
    The goalkeeper at the front end of the ventilation system, stable and durable
    🟦 What problems can this product help you solve? Based on customer feedback, this commercial MERV 8 filter...
    read more
  • Aluminum Frame G4 Panel Filter
    Replaceable-Pad Aluminum Frame G4 Panel Filter | AHU Pre Filter
    Reusable aluminum frame with replaceable G4 non-woven pad for AHU pre-filtration, retrofit projects and routine HVAC...
    read more
  • Reusable Hvac Filter
    Reusable Pleated HVAC Filter for First-Stage Dust Control
    Reusable pleated HVAC filter with metal wire mesh support and non-woven media. Designed for first-stage dust control, low airflow...
    read more
First 1234 Last


Our Best-Selling Pre Filter Types

Washable Air Filter

Washable air filters can be rinsed with water or vacuumed to remove any ­particle buildup. Washable air filters are typically made out of woven polypropylene media and are electrostatically charged in order to capture more particles.



Panel Filter

Panel filters are a type of filter used in HVAC (heating, ventilation & air conditioning) systems. They're installed in a panel near the blower unit and work to remove dust and other debris from the air before it is circulated through the building's ductwork system.



Pleated Filter

Pleated filters are made from pleated cloth or paper that is pleated or folded in a series of small pleats, which help to increase the filter's surface area and capture more particles. This type of filter is often used in air conditioning systems, air purifiers, and other indoor air quality devices.





Why Choose Us

Advanced Equipment

We are equipped with clean room production lines, advanced R&D centers and precision testing equipment.

Professional Team

We have formed an experienced and skilled professional team to ensure that our products and services always maintain the leading level in the industry.

Patent Certificate

We have successfully obtained ISO 9001:2015 quality management system certification and comply with ISO 9001 standards, EN 779:2012 regulations and CE marking requirements.

Quality Control

We implement strict control on product quality to ensure that each product meets high quality requirements.





Pre Filter Technical Parameters



Size :

610 x 610 x 50/100 / 150 mm

Type :

Box / Flange Type

Filtr. Level :

90% Down to 10 Micron

Initial Pressure Drop :

3 mm of W.G.

Final Pressure Drop :

15 / 20 mm of W.G.

Frame :

G.I. / Cardboard

Media :

HDPE / Synthetic Fibre



Pre Filter Advantages


Lower pressure drop

Easy to install in wide range of HVAC systems

High moisture resistant

Cost saving with lower energy consumption

Environment friendly

To extend life span on final filtration



Common Materials Used for Pre Filter



Polyester:

Provides good filtration.

01

Fiberglass:

Durable material with reasonable efficiency for the price.

02

Foam:

Can trap large particles, some models are washable and reusable.

03

Mesh screens:

Allows high airflow while catching large debris.

04

Pleated filters:

Offer more surface area for higher particle capture than flat filters.

05



The Role of Pre Filter



Protect the main filters:

By trapping hair, dust and other large particles, pre-filters help maintain airflow through the system and prevent clogging of the HEPA, activated carbon and other filters.

Improve air quality:

Pre-filters do capture many large airborne particles that can irritate allergies and asthma. While they allow smaller particles like smoke and pollen to pass through, pre-filters still contribute to cleaning indoor air.

Pleated Air Conditioner Filters



Applications of Pre Filter



HVAC systems:

To protect expensive HEPA filters or other fine filters in commercial and residential settings.





Air purifiers:

To extend the lifespan of the main filter by catching larger particles.





Vacuum cleaners:

To prevent larger debris from clogging the vacuum’s motor.





Our service



Pre-sales Service:



Needs Analysis:

Communicate to understand customer requirements and goals.

01

Product Consultation:

Provide product details for customers to choose suitable options.

02

Solution Design:

Create personalized solutions based on needs.

03

Cost Estimation:

Offer transparent cost estimates and quotations.

04

Sample Provision:

Provide samples for customer testing when needed.

05



During Sales Service:


Order Tracking:

Ensure timely and accurate order processing with status updates.

Production Supervision:

Monitor production to ensure quality standards are met.

Logistics Coordination:

Arrange logistics for on-time and safe delivery.

Technical Support:

Offer support for installation and configuration questions.



After-sales Service:


Installation Guidance:

Provide professional installation guidance.

Operational Training:

Train customers to skillfully use products.

Maintenance Services:

Regularly offer maintenance and inspection services.

Fault Response:

Respond quickly to malfunctions with solutions or on-site services.

Spare Parts Supply:

Provide necessary spare parts for continuous operation.

Customer Feedback:

Collect feedback to improve products and services.



Packaging and Delivery



Packaging

Anti-corrosion film + reinforced wooden crates

Delivery

DDP/DAP options with real-time tracking



Our Certificate



productcate-1-1
productcate-1-1
productcate-1-1
productcate-1-1
productcate-1-1
productcate-1-1



FAQ

Q: What is the function of a pre-filter?

A: Regardless of the material, the primary function of a pre-filter is to trap larger particles before they reach the more advanced filters in the purification system.

Q: Why is a pre filter recommended?

A: A pre-filter is used to filter dust, pollen, fibres, and other visible impurities before further purification by other filters. This filter also prevents these physical impurities from clogging the purifier, thus extending the life of your purifier.

Q: Do pre-filters restrict airflow?

A: Protect the main filters - By trapping hair, dust and other large particles, pre-filters help maintain airflow through the system and prevent clogging of the HEPA, activated carbon and other filters.

Q: What is the principle of pre filter?

A: Comprising densely woven materials like fiberglass, polyester, or cotton, pre-filters create a barrier through which air passes. As air flows through the pre-filter, larger particles are unable to penetrate the fibres and are thus captured, both on the surface and within the depth of the filter media.

Q: How does a pre-filter work?

A: A pre-filter is a filtering device that removes large particles from the air before it reaches the main filter, including dust, hair, insects, pollen, and various fibers.

We're professional pre filter manufacturers and suppliers in China, specialized in providing high quality products and service. We warmly welcome you to wholesale customized pre filter from our factory.
